Volume pricing
- 1+ pcs$0.56
- 10+ pcs$0.52
- 100+ pcs$0.49
- 500+ pcs$0.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.50.90.40
- Illumination Type
- Non-Illuminated
- Contact Dc Max Rating R Load
- .3A@6VDC
- Switch Function
- On-On
- Insulation Materials
- GLASS FILLED NYLON
- Pozisyon Sayısı
- 2
- Terminal
- PC Pin
- Insulation Resistance
- 100000000Ohm
- JESD-609 Kodu
- e4
- Voltage Rated Ac
- 6V
- Actuator Material
- Polyamide (PA66), Nylon 6/6
- Contact Currentdcmax
- 0.3A
- Seri
- MHSS
- Montaj Tipi
- Through Hole
- Washability
- PARTIAL
- Özellikler
- Black Actuator
- Current Rating Amps
- 300mA DC
- Housing Material
- GLASS FILLED NYLON
- Electricallife
- 5,000 Cycles
- Çalışma Sıcaklığı
- -20°C~70°C
- Montaj
- Through Hole
- Actuator Type
- Standard
- Parça Durumu
- Active
- Voltage Rated Dc
- 6V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 100VAC V
- Switch Type
- SLIDE SWITCH
- Body Breadth
- 3.5 mm
- Contact Resistance
- 60mOhm
- Terminal Stili
- PC Pin
- Pcb Hole Count
- 6
- Solderability
- WAVE
- Max Voltage Rating Dc
- 6V
- Contact Current Rating
- 300mA
- Orientation
- Straight
- Body Length Or Diameter
- 8.5mm
- Contact Timing
- Not Specified
- Circuit
- SPDT
- Contact Finish
- Silver
- RoHS Durumu
- ROHS3 Compliant
