Specifications
- Switch Function
- On-On-On
- Contact Dc Max Rating R Load
- .3A@30VDC
- HTS Kodu
- 8536.50.90.50
- Terminal
- PC Pin
- JESD-609 Kodu
- e4
- Actuator Material
- Aluminum Alloy
- Contact Currentdcmax
- 0.3A
- Switch Travel
- 2.00mm
- Özellikler
- Epoxy Sealed Terminals
- Montaj Tipi
- Through Hole
- Seri
- MHS
- Electricallife
- 10,000 Cycles
- Current Rating Amps
- 300mA DC
- Housing Material
- Steel
- Çalışma Sıcaklığı
- -20°C~85°C
- Parça Durumu
- Active
- Actuator Type
- Baton
- Montaj
- Brackets, Through Hole
- Switch Type
- SLIDE SWITCH
- Voltage Rated Dc
- 30V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- PC Pin
- Operating Force
- 250gf
- Contact Resistance
- 20mOhm
- Body Breadth
- 6.8 mm
- Contact Current Rating
- 300mA
- Orientation
- Straight
- Contact Timing
- Not Specified
- Body Length Or Diameter
- 16mm
- Contact Materials
- Brass
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Bulk
- Sealing
- EPOXY TERMINAL SEALED
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish
- Silver
- Circuit
- DP3T
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 8 Weeks
- Body Height
- 7.5mm
- Akım Değeri
- 300mA
