Specifications
- Temel Parça No
- AD8328
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Operating Supply Voltage
- 5V
- Kurşunsuz Kodu
- no
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Contains Lead
- Tepe Reflow Sıcaklığı (°C)
- 220
- JESD-609 Kodu
- e0
- Gain Bandwidth Product
- 107MHz
- Number Of Channels
- 1
- ECCN Kodu
- EAR99
- Differential Output
- YES
- Power Dissipation
- 700mW
- Temperature Grade
- INDUSTRIAL
- Voltage Gain
- 32.5dB
- Min Supply Voltage
- 4.75V
- Tip
- Line Driver, Transmitter
- Pin Sayısı
- 20
- Uzunluk
- 4mm
- Besleme Gerilimi
- 5V
- Interface Standards
- GENERAL PURPOSE
- Fonksiyon Sayısı
- 1
- Driver Number Of Bits
- 1
- RoHS Durumu
- Non-RoHS Compliant
- Max Supply Voltage
- 5.25V
- Maks. Çalışma Sıcaklığı
- 85°C
- Montaj
- Surface Mount
- Parça Durumu
- Obsolete
- Kılıf / Paket
- 20-VFQFN Exposed Pad, CSP
- Direnç
- 1.6kOhm
- Input Characteristics
- DIFFERENTIAL
- Tepe Reflow Süresi (maks. sn)
- 30
- Terminal Sayısı
- 20
- Pin Sayısı
- 20
- Nominal Supply Current
- 120mA
- Radyasyon Dayanımı
- No
- Montaj Tipi
- Surface Mount
- Terminal Adımı
- 0.5mm
- Terminal Pozisyonu
- QUAD
- Min. Çalışma Sıcaklığı
- -40°C
