Specifications
- Terminal Sayısı
- 20
- Tepe Reflow Sıcaklığı (°C)
- 260
- Ratio Shadc
- 1:1
- Parça Durumu
- Active
- Kılıf / Paket
- 20-WFQFN Exposed Pad, CSP
- Data Interface
- SPI, DSP
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 20
- Montaj Tipi
- Surface Mount
- Resolution
- 1.5 B
- Output Bit Code
- BINARY
- Terminal Kaplaması
- Tin (Sn)
- Yükseklik
- 1.05mm
- Max Input Voltage
- 5.25V
- Sampling Rate Per Second
- 1M
- Fonksiyon Sayısı
- 1
- Ambalaj
- Tray
- Montaj
- Surface Mount
- Number Of Bits
- 12
- Conversion Timemax
- 0.6μs
- Min Input Voltage
- 1V
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Number Of Inputs
- 1
- Operating Supply Voltage
- 5.25V
- Number Of Analog In Channels
- 4
- Pin Sayısı
- 20
- Tepe Reflow Süresi (maks. sn)
- 30
- Kurşunsuz
- Contains Lead
- Number Of Analog Inputs
- 4
- Differential Nonlinearity
- 0.3 LSB
- Configuration
- S/H-ADC
- Besleme Gerilimi
- 3V
- Polarity
- Unipolar
- Power Dissipation
- 3.4mW
- Kurşunsuz Kodu
- no
- Voltage Supply Digital
- 2.09V~5.25V
- Interface
- SPI
- Terminal Adımı
- 0.5mm
- Operating Supply Current
- 500μA
- Çalışma Sıcaklığı
- -40°C~125°C
