Specifications
- Polarity
- Unipolar
- Montaj
- Surface Mount
- Kurşunsuz Kodu
- no
- Temel Parça No
- AD5620
- Parça Durumu
- Active
- Pin Sayısı
- 8
- Seri
- nanoDAC®
- Terminal Sayısı
- 8
- Settling Time
- 10μs
- Uzunluk
- 3mm
- Besleme Gerilimi
- 3V
- Input Bit Code
- BINARY
- Min Supply Voltage
- 4.5V
- Number Of Converters
- 1
- Max Input Voltage
- 2.5V
- Number Of Bits
- 12
- Slew Rate
- 1.5 V/μs
- Conversion Rate
- 125 ksps
- Resolution
- 1.5 B
- Differential Output
- No
- Power Dissipation
- 5.5mW
- Fonksiyon Sayısı
- 1
- Terminal Adımı
- 0.65mm
- Kurşunsuz
- Contains Lead
- Converter Type
- D/A CONVERTER
- RoHS Durumu
- ROHS3 Compliant
- Min Output Voltage
- 0V
- Inldnl Lsb
- ±1 (Max), ±0.25 (Max)
- Differential Nonlinearity
- 0.25 LSB
- Montaj Tipi
- Surface Mount
- Min Input Voltage
- 1.25V
- Data Interface
- SPI, DSP
- Çıkış Tipi
- Voltage - Buffered
- Genişlik
- 3mm
- Ambalaj
- Tape & Reel (TR)
- Reference Type
- Internal
- Interface
- SPI, Serial
- Terminal Pozisyonu
- DUAL
- Max Supply Voltage
- 5.5V
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
