Volume pricing
- 1+ pcs$1.26
- 10+ pcs$1.19
- 100+ pcs$1.12
- 500+ pcs$1.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Conversion Rate
- 1.7 Msps
- Differential Output
- No
- Resolution
- 1.25 B
- Power Dissipation
- 550μW
- Fonksiyon Sayısı
- 1
- Number Of Dac Channels
- 1
- Kurşunsuz
- Contains Lead
- Converter Type
- D/A CONVERTER
- RoHS Durumu
- ROHS3 Compliant
- Min Output Voltage
- 2.7V
- Inldnl Lsb
- ±4 (Max), ±0.5 (Max)
- Fabrika Tedarik Süresi
- 8 Weeks
- Input Bit Code
- BINARY
- Min Supply Voltage
- 2.7V
- Max Input Voltage
- 5.5V
- Number Of Bits
- 10
- Slew Rate
- 0.5 V/μs
- Pin Sayısı
- 6
- Tepe Reflow Sıcaklığı (°C)
- 260
- Contact Plating
- Tin
- Seri
- nanoDAC®
- Tepe Reflow Süresi (maks. sn)
- 30
- Terminal Sayısı
- 6
- Lifecycle Status
- PRODUCTION (Last Updated: 2 weeks ago)
- Supply Type
- Single
- Settling Time
- 10μs
- Uzunluk
- 3mm
- Nominal Supply Current
- 75μA
- Besleme Gerilimi
- 3V
- Reach Svhc
- No SVHC
- JESD-609 Kodu
- e3
- Power Supplies
- 3/5V
- Polarity
- Unipolar
- Temel Parça No
- AD5611
- Kurşunsuz Kodu
- no
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~125°C
- Integral Nonlinearity Inl
- 4 LSB
- ECCN Kodu
- EAR99
- Max Supply Voltage
- 5.5V
