Specifications
- Inldnl Lsb
- ±0.25 (Max), ±0.5 (Max)
- Contact Plating
- Tin
- Voltage Supply Analog
- 2.5V~5.5V
- Sampling Rate
- 20.4 Msps
- Reference Type
- External
- Terminal Adımı
- 0.5mm
- Integral Nonlinearity Inl
- 0.25 LSB
- Pin Sayısı
- 20
- Architecture
- R-2R
- Terminal Sayısı
- 20
- Conversion Rate
- 20.4 Msps
- Min Output Voltage
- 0V
- Kılıf / Paket
- 20-WFQFN Exposed Pad, CSP
- Yüzey Montaj
- YES
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Operating Supply Voltage
- 5V
- Power Dissipation
- 2.2μW
- Linearity Errormax El
- 0.0977%
- Settling Time
- 120ns
- Genişlik
- 4mm
- Converter Type
- D/A CONVERTER
- Ambalaj
- Tray
- Uzunluk
- 4mm
- Data Interface
- Parallel
- Tepe Reflow Sıcaklığı (°C)
- 260
- Fabrika Tedarik Süresi
- 8 Weeks
- Max Supply Voltage
- 5.5V
- Fonksiyon Sayısı
- 1
- Tepe Reflow Süresi (maks. sn)
- 40
- Resolution
- 1 B
- Yükseklik
- 830μm
- Lifecycle Status
- PRODUCTION (Last Updated: 3 weeks ago)
- Çalışma Sıcaklığı
- -40°C~125°C
- Temel Parça No
- AD5424
- Voltage Supply Digital
- 2.5V~5.5V
- Çıkış Tipi
- Current - Unbuffered
- Number Of Bits
- 8
- Reach Svhc
- No SVHC
- Max Output Voltage
- 20V
- Number Of Converters
- 1
