Volume pricing
- 1+ pcs$0.29
- 10+ pcs$0.27
- 100+ pcs$0.26
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 11 Weeks
- Number Of Contacts
- 8
- Current Rating Amps
- 1A
- Contact Plating
- Tin
- Contact Resistance
- 30mOhm
- Depth
- 6.8mm
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Cable End Type
- Straight, Tapered
- Sıra Sayısı
- 1
- Ffc Fcb Thickness
- 0.30mm 0.33mm
- Montaj
- Through Hole
- Min. Çalışma Sıcaklığı
- -55°C
- Flammability Rating
- UL94 V-0
- Wirecable Type
- Straight
- Contact Location
- Bottom
- Mating Cycles
- 20
- Insulation Resistance
- 500MOhm
- Housing Material
- Polyamide (PA), Nylon, Glass Filled
- Max Voltage Rating Ac
- 100V
- Material Flammability Rating
- UL94 V-0
- Pitch
- 0.039 1.00mm
- Housing Color
- Black
- Uzunluk
- 14.2mm
- Flat Flex Type
- FFC, FPC
- Pozisyon Sayısı
- 8
- Seri
- SLW-R
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole, Right Angle
- Nominal Gerilim
- 100V
- Akım Değeri
- 1A
- Locking Feature
- Slide Lock
- Maks. Çalışma Sıcaklığı
- 85°C
- Terminal
- Kinked Pin
- Height Above Board
- 0.157 4.00mm
- Max Voltage Rating Dc
- 100V
- Özellikler
- Zero Insertion Force (ZIF)
- Voltage Rated Ac
- 100V
- Actuatorcolor
- Black
- Çalışma Sıcaklığı
- -55°C~85°C
- Ambalaj
- Tray
