Specifications
- Flammability Rating
- UL94 V-0
- Wirecable Type
- Straight
- Contact Location
- Bottom
- Mating Cycles
- 20
- Yayın Yılı
- 2005
- Montaj
- Through Hole
- Min. Çalışma Sıcaklığı
- -55°C
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Cable End Type
- Straight, Tapered
- Sıra Sayısı
- 1
- Ffc Fcb Thickness
- 0.30mm 0.33mm
- Fabrika Tedarik Süresi
- 11 Weeks
- Number Of Contacts
- 26
- Current Rating Amps
- 1A
- Contact Plating
- Tin
- Nominal Gerilim
- 100V
- Montaj Tipi
- Through Hole
- Parça Durumu
- Active
- Uzunluk
- 32.2mm
- Flat Flex Type
- FFC, FPC
- Pozisyon Sayısı
- 26
- Seri
- SLW-S
- Housing Material
- Polyamide (PA), Nylon, Glass Filled
- Insulation Resistance
- 500MOhm
- Material Flammability Rating
- UL94 V-0
- Pitch
- 0.039 1.00mm
- Housing Color
- Black
- Height Above Board
- 0.217 5.50mm
- Yükseklik
- 5.5mm
- Maks. Çalışma Sıcaklığı
- 85°C
- Terminal
- Kinked Pin
- Akım Değeri
- 1A
- Locking Feature
- Slide Lock
- Orientation
- Straight
- Contact Materials
- Phosphor Bronze
- Genişlik
- 4mm
- Contact Finish
- Tin
- Ambalaj
- Tray
- Kurşunsuz
- Lead Free
- Gender
- Receptacle
