Specifications
- Ffc Fcb Thickness
- 0.30mm 0.33mm
- Contact Resistance
- 30mOhm
- Fabrika Tedarik Süresi
- 11 Weeks
- Wirecable Type
- Straight
- Flammability Rating
- UL94 V-0
- Mating Cycles
- 20
- Montaj
- Through Hole
- Total Number Of Contacts
- 24
- Uzunluk
- 30.2mm
- Pitch
- 0.039 1.00mm
- Insulation Resistance
- 500MOhm
- Mixed Contacts
- NO
- Parça Durumu
- Active
- Locking Feature
- Slide Lock
- Mil Conformance
- NO
- Height Above Board
- 0.157 4.00mm
- Terminal
- Kinked Pin
- Contact Gender
- FEMALE
- Çalışma Sıcaklığı
- -55°C~85°C
- Voltage Rated Ac
- 100V
- Max Voltage Rating Dc
- 100V
- Connector Type
- FFC/FPC CONNECTOR
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Ambalaj
- Tray
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Sıra Sayısı
- 1
- Cable End Type
- Straight, Tapered
- Depth
- 6.8mm
- ECCN Kodu
- EAR99
- Contact Location
- Bottom
- Flat Flex Type
- FFC, FPC
- Pozisyon Sayısı
- 24
- Seri
- SLW-R
- Din Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Black
- Housing Material
- Polyamide (PA), Nylon, Glass Filled
- Max Voltage Rating Ac
- 100V
- Ul Flammability Code
- 94V-0
