Volume pricing
- 1+ pcs$0.67
- 10+ pcs$0.63
- 100+ pcs$0.60
- 500+ pcs$0.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Flat Flex Type
- FFC, FPC
- Material Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- Mating Cycles
- 20
- Parça Durumu
- Active
- Mixed Contacts
- NO
- Uzunluk
- 27.8mm
- Iec Conformance
- NO
- Max Voltage Rating Dc
- 100V
- Cable End Type
- Straight, Tapered
- Sıra Sayısı
- 1
- Depth
- 6mm
- Terminal
- Solder
- Total Number Of Contacts
- 22
- Contact Gender
- FEMALE
- Mil Conformance
- NO
- Akım Değeri
- 1A
- Yayın Yılı
- 2009
- Ffc Fcb Thickness
- 0.30mm 0.33mm
- Pozisyon Sayısı
- 22
- Housing Material
- Polyphenylene Sulfide (PPS), Glass Filled
- Seri
- SFW-R
- Contact Materials
- Phosphor Bronze
- Ul Flammability Code
- 94V-0
- Fabrika Tedarik Süresi
- 13 Weeks
- Actuator Material
- Polyphenylene Sulfide (PPS), Glass Filled
- Flammability Rating
- UL94 V-0
- JESD-609 Kodu
- e3
- Wirecable Type
- Straight
- Max Voltage Rating Ac
- 100V
- Option
- GENERAL PURPOSE
- Housing Color
- Brown
- Çalışma Sıcaklığı
- -55°C~105°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Din Conformance
- NO
- Genişlik
- 5.5mm
- Pitch
- 0.039 1.00mm
- Voltage Rated Ac
- 100V
- Özellikler
- Zero Insertion Force (ZIF)
