Volume pricing
- 1+ pcs$0.18
- 10+ pcs$0.17
- 100+ pcs$0.16
- 500+ pcs$0.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pozisyon Sayısı
- 8
- Contact Finish
- Gold
- Actuator Material
- Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free
- Sıra Sayısı
- 1
- Option
- GENERAL PURPOSE
- Radyasyon Dayanımı
- No
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Ffc Fcb Thickness
- 0.33mm
- Seri
- SFV-R
- Parça Durumu
- Active
- Housing Color
- Black
- Current Rating Amps
- 0.5A
- Mixed Contacts
- NO
- Flat Flex Type
- FPC
- Din Conformance
- NO
- Ul Flammability Code
- 94V-0
- Montaj
- Surface Mount
- Mating Cycles
- 20
- Locking Feature
- Slide Lock
- Contact Materials
- Phosphor Bronze
- Flammability Rating
- UL94 V-0
- Pitch
- 0.020 0.50mm
- Montaj Tipi
- Surface Mount, Right Angle
- Ambalaj
- Tape & Reel (TR)
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 14 Weeks
- Cable End Type
- Notched
- Contact Gender
- FEMALE
- Insulation Resistance
- 100MOhm
- Housing Material
- Polyamide (PA), Nylon, Glass Filled, Halogen Free
- Height Above Board
- 0.071 1.80mm
- Iec Conformance
- NO
- Contact Location
- Bottom
- Orientation
- Right Angle
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Akım Değeri
- 500mA
- Filter Feature
- NO
- Nominal Gerilim
- 50V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
