Volume pricing
- 1+ pcs$0.34
- 10+ pcs$0.32
- 100+ pcs$0.30
- 500+ pcs$0.28
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wirecable Type
- Straight
- Contact Materials
- Phosphor Bronze
- Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Ffc Fcb Thickness
- 0.30mm 0.33mm
- Min. Çalışma Sıcaklığı
- -55°C
- Housing Color
- Black
- Contact Resistance
- 30mOhm
- Current Rating Amps
- 0.5A
- Depth
- 4.2mm
- Contact Finish
- Tin
- Actuator Material
- Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2011
- Contact Location
- Top
- Akım Değeri
- 500mA
- Uzunluk
- 9.5mm
- Housing Material
- Polyamide (PA), Nylon, Glass Filled, Halogen Free
- Height Above Board
- 0.071 1.80mm
- Cable End Type
- Straight, Tapered
- Gender
- Receptacle
- Maks. Çalışma Sıcaklığı
- 105°C
- Pitch
- 0.020 0.50mm
- Montaj Tipi
- Surface Mount, Right Angle
- Ambalaj
- Tape & Reel (TR)
- Max Voltage Rating Dc
- 50V
- Flat Flex Type
- FFC, FPC
- Montaj
- Surface Mount
- Mating Cycles
- 20
- Locking Feature
- Slide Lock
- Seri
- SFV-R
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Pozisyon Sayısı
- 8
- Sıra Sayısı
- 1
- Radyasyon Dayanımı
- No
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~105°C
- Max Voltage Rating Ac
- 50V
