Volume pricing
- 1+ pcs$1.03
- 10+ pcs$0.97
- 100+ pcs$0.92
- 500+ pcs$0.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Ports
- 1
- Contact Finish
- Gold
- Gender
- Female
- Maks. Çalışma Sıcaklığı
- 125°C
- Depth
- 21.7mm
- Connector Style
- D-Sub, High Density
- Renk
- Black
- Shell Material Finish
- Steel, Tin Plated
- Contact Plating
- Gold
- Max Voltage Rating Ac
- 300V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Material
- Polyester
- Nominal Gerilim
- 300V
- Pitch
- 2.28mm
- RoHS Durumu
- RoHS Compliant
- Current Rating Amps
- 3A
- Kurşunsuz
- Lead Free
- Contact Finish Thickness
- Flash
- Min. Çalışma Sıcaklığı
- -55°C
- Montaj
- Through Hole
- Shell Size Connector Layout
- 1 DE E High Density
- Uzunluk
- 30.81mm
- Contact Materials
- Copper Alloy
- Özellikler
- Board Lock, Mounting Brackets
- Housing Material
- Polyester
- Montaj Tipi
- Through Hole, Right Angle
- Material Flammability Rating
- UL94 V-0
- Terminal Sayısı
- 15
- Ambalaj
- Tray
- Parça Durumu
- Active
- Backset Spacing
- 0.350 (8.89mm)
- Çalışma Sıcaklığı
- -55°C~125°C
- Fabrika Tedarik Süresi
- 12 Weeks
- Max Supply Voltage Ac
- 300V
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Radyasyon Dayanımı
- No
- Connector Type
- Receptacle, Female Sockets
- Seri
- ICD
- Pin Sayısı
- 15
- Pozisyon Sayısı
- 15
