Volume pricing
- 1+ pcs$5.53
- 10+ pcs$5.22
- 100+ pcs$4.93
- 500+ pcs$4.65
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Connector Style
- D-Sub, Combo
- Terminal Sayısı
- 7
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Working Voltage
- 500V
- Body Material
- Steel
- Dielectric Material
- Thermoplastic
- Uzunluk
- 38.76mm
- Depth
- 13.85mm
- Body Plating
- Nickel
- Fabrika Tedarik Süresi
- 8 Weeks
- Housing Material
- Thermoplastic
- Contact Materials
- Phosphor Bronze
- Current Rating Amps
- 7.5A
- Çalışma Sıcaklığı
- -55°C~125°C
- Genişlik
- 12.55mm
- Number Of Contacts
- 7
- Number Of Power Positions
- 2
- Contact Resistance
- 7.3mOhm
- Nominal Gerilim
- 300V
- Gender
- Receptacle
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 7.5A
- Max Supply Voltage Ac
- 300V
- Max Voltage Rating Ac
- 300V
- Wirecable Gauge
- 20 AWG
- Flammability Rating
- UL94 V-0
- Number Of Ports
- 1
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Radyasyon Dayanımı
- No
- Shell Material Finish
- Steel, Tin Plated
- Contact Finish
- Gold-Palladium
- Connector Type
- Receptacle, Female Sockets
- Montaj
- Free Hanging, Panel
- Montaj Tipi
- Free Hanging (In-Line)
- Shell Material
- Steel
- Terminal
- Solder Cup
- Seri
- DW
- Ambalaj
- Tray
