Volume pricing
- 1+ pcs$1.91
- 10+ pcs$1.80
- 100+ pcs$1.70
- 500+ pcs$1.60
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reach Svhc
- No SVHC
- Contact Type
- Signal
- Parça Durumu
- Active
- Akım Değeri
- 5A
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 39.14mm
- Terminal
- Solder
- Housing Material
- Polybutylene
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Connector Type
- Plug, Male Pins
- Number Of Contacts
- 15
- Body Plating
- Tin
- Contact Materials
- Phosphor Bronze
- Pitch
- 2.74mm
- Orientation
- Straight
- Genişlik
- 11.9mm
- Kurşunsuz
- Lead Free
- Body Material
- Metal
- Current Rating Amps
- 5A
- Shell Material Finish
- Steel, Tin Plated
- Contact Finish Thickness
- Flash
- Max Supply Voltage Ac
- 300V
- Çalışma Sıcaklığı
- -55°C~125°C
- Fabrika Tedarik Süresi
- 11 Weeks
- Pozisyon Sayısı
- 15
- Maks. Çalışma Sıcaklığı
- 125°C
- Max Voltage Rating Ac
- 300V
- Montaj
- Through Hole
- Ambalaj
- Tray
- Terminal Sayısı
- 15
- Seri
- Delta D
- Housing Color
- Black
- Material Flammability Rating
- UL94 V-0
- Shell Size Connector Layout
- 2 DA A
- Contact Finish
- Gold
- Montaj Tipi
- Through Hole
- Number Of Ports
- 1
- Sıra Sayısı
- 2
- Contact Resistance
- 10mOhm
- Dielectric Material
- Polybutylene Terephthalate (PBT)
