Volume pricing
- 1+ pcs$1.06
- 10+ pcs$1.00
- 100+ pcs$0.94
- 500+ pcs$0.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Phosphor Bronze
- Contact Type
- Male Pin
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Kurşunsuz
- Lead Free
- Nominal Gerilim
- 1.5kV
- Insulation Materials
- Thermoplastic
- Akım Değeri
- 3A
- Contact Finish Post
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Positions Loaded
- All
- Pitch
- 2.54mm
- Depth
- 4.83mm
- Reach Svhc
- No SVHC
- Insulation Color
- Black
- Contact Shape
- Square
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Maks. Çalışma Sıcaklığı
- 125°C
- Contact Finish Mating
- Gold, GXT™
- Uzunluk
- 10.16mm
- Mating Post Length
- 5.84mm
- Contact Lengthmating
- 0.232 5.90mm
- Seri
- BERGSTIK®
- Max Voltage Rating Ac
- 1.5kV
- Housing Material
- Thermoplastic
- Lead Pitch
- 2.54mm
- Terminal
- Solder
- Sıra Sayısı
- 2
- Number Of Contacts
- 8
- Fabrika Tedarik Süresi
- 6 Weeks
- Connector Type
- Header, Breakaway
- Row Spacing Mating
- 0.100 (2.54mm)
- Gender
- Male
- Housing Color
- Black
- Insulation Resistance
- 5GOhm
- Parça Durumu
- Active
- Contact Plating
- Gold
- Özellikler
- Pick and Place
- Material Flammability Rating
- UL94 V-0
- Style
- Board to Board
- Contact Gender
- Male
