Specifications
- Housing Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Mounting Option1
- LOCKING
- Gender
- Female Sockets
- Body Depth
- 0.138 inch
- Yükseklik
- 0.138 3.50mm
- Polarization Key
- POLARIZED HOUSING
- Reference Standard
- UL, CSA
- Orientation
- Straight
- Total Number Of Contacts
- 2
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- COPPER ALLOY
- Parça Durumu
- Active
- Operating Temperature Max
- 105°C
- Renk
- Black
- Insulation Resistance
- 1000000000Ohm
- Fabrika Tedarik Süresi
- 7 Weeks
- Pin Sayısı
- 2
- Sıra Sayısı
- 1
- Seri
- Minitek® 2.00mm
- Reliability
- COMMERCIAL
- Number Of Positions Or Pins Grid
- 2 (1 x 2)
- Current Rating Amps
- 1A
- Pitch
- 0.079 2.00mm
- Number Of Conductors
- ONE
- Body Length Or Diameter
- 0.157 inch
- Plating Thickness
- 15μin
- Contact Pattern
- RECTANGULAR
- Material Flammability Rating
- UL94 V-0
- Tip
- Open Top
- Operating Temperature Min
- -40°C
- Body Breadth
- 0.079 inch
- Durability
- 30 Cycles
- Contact Finish
- Gold
- Contact Finish Thickness
- 15.0μin 0.38μm
- Contact Style
- SQ PIN-SKT
- RoHS Durumu
- RoHS Compliant
