Specifications
- Insulation Height
- 0.190 4.83mm
- Akım Değeri
- 3A
- Renk
- Black
- Contact Finish Post
- Tin
- Housing Material
- Thermoplastic
- Depth
- 13.38mm
- Kurşunsuz
- Lead Free
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Contact Lengthmating
- 0.268 6.80mm
- Pitch Mating
- 0.100 2.54mm
- Max Voltage Rating Ac
- 1.5kV
- Fastening Type
- Push-Pull
- Nominal Gerilim
- 1.5kV
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Min. Çalışma Sıcaklığı
- -65°C
- Fabrika Tedarik Süresi
- 8 Weeks
- Orientation
- Right Angle
- Housing Color
- Black
- Insulation Resistance
- 5GOhm
- Material Flammability Rating
- UL94 V-0
- Flammability Rating
- UL94 V-0
- Contact Finish Mating
- Tin
- Contact Plating
- Lead, Tin
- Connector Type
- Header, Breakaway
- Contact Finish Thickness Mating
- 78.7μin 2.00μm
- Contact Length Post
- 0.120 3.05mm
- Style
- Board to Board
- Number Of Contacts
- 48
- Ambalaj
- Bulk
- Pozisyon Sayısı
- 48
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 2
- Contact Type
- Male Pin
- Uzunluk
- 60.96mm
- Montaj Tipi
- Through Hole, Right Angle
- Insulation Color
- Black
- Shrouding
- Unshrouded
- Contact Shape
- Square
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
