Volume pricing
- 1+ pcs$0.06
- 10+ pcs$0.06
- 100+ pcs$0.05
- 500+ pcs$0.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım Değeri
- 3A
- Insulation Height
- 0.100 2.54mm
- Contact Finish Post
- Tin
- Renk
- Black
- Housing Material
- Thermoplastic
- Terminal
- Solder
- Depth
- 2.4mm
- Material
- Thermoplastic
- Contact Materials
- Phosphor Bronze
- Kurşunsuz
- Lead Free
- Max Voltage Rating Ac
- 1.5kV
- Pitch Mating
- 0.100 2.54mm
- Contact Lengthmating
- 0.230 5.84mm
- Min. Çalışma Sıcaklığı
- -65°C
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Fastening Type
- Push-Pull
- Nominal Gerilim
- 1.5kV
- Lead Length
- 2.41mm
- Yayın Yılı
- 2009
- Insulation Resistance
- 5GOhm
- Housing Color
- Black
- Fabrika Tedarik Süresi
- 7 Weeks
- Orientation
- Straight
- Reach Svhc
- No SVHC
- Connector Type
- Header
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Contact Finish Mating
- Gold or Gold, GXT™
- Contact Plating
- Gold
- Flammability Rating
- UL94 V-0
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Number Of Contacts
- 2
- Contact Length Post
- 0.095 2.41mm
- Style
- Board to Board
- Mating Post Length
- 5.84mm
- Overall Contact Length
- 0.425 10.80mm
- Contact Type
- Male Pin
- Uzunluk
- 5.08mm
- Pozisyon Sayısı
- 2
- Sıra Sayısı
- 1
