Specifications
- Number Of Contacts
- 10
- Nominal Gerilim
- 1kV
- Seri
- Dubox™
- Stack Height
- 7mm
- Insulation Height
- 0.275 6.99mm
- Contact Finish Post
- Tin
- Uzunluk
- 12.62mm
- Pozisyon Sayısı
- 10
- Pitch
- 2.54mm
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 20mOhm
- Min. Çalışma Sıcaklığı
- -65°C
- Kurşunsuz
- Lead Free
- Number Of Poles
- 10
- Contact Finish Mating
- Gold
- Parça Durumu
- Active
- Insulation Resistance
- 100GOhm
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Sıra Sayısı
- 2
- Depth
- 5.08mm
- Contact Materials
- Phosphor Bronze
- Contact Plating
- Gold
- Insulation Color
- Blue
- Housing Material
- Thermoplastic
- Material Flammability Rating
- UL94 V-0
- Contact Length Post
- 0.114 2.90mm
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Maks. Çalışma Sıcaklığı
- 125°C
- Reach Svhc
- No SVHC
- Terminal
- Solder
- Pitch Mating
- 0.100 2.54mm
- Orientation
- Straight
- Connector Type
- Receptacle
- Radyasyon Dayanımı
- No
- Contact Type
- Female Socket
- Insulation Materials
- Thermoplastic, Glass Filled
- Montaj
- Through Hole
- Gender
- Receptacle
- Housing Color
- Blue
