Volume pricing
- 1+ pcs$0.62
- 10+ pcs$0.59
- 100+ pcs$0.55
- 500+ pcs$0.52
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Finish Mating
- Gold
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Montaj
- Through Hole
- Seri
- Dubox™
- Contact Length Post
- 0.114 2.90mm
- Uzunluk
- 15.16mm
- Contact Materials
- Phosphor Bronze
- Akım Değeri
- 3A
- Kurşunsuz
- Lead Free
- Terminal
- Solder
- Ambalaj
- Tube
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 1kV
- Renk
- Blue
- Housing Material
- Thermoplastic
- Number Of Positions Loaded
- All
- Contact Finish Post
- Tin
- Pitch Mating
- 0.100 2.54mm
- Contact Shape
- Square
- Style
- Board to Board
- Min. Çalışma Sıcaklığı
- -65°C
- Fastening Type
- Push-Pull
- Sıra Sayısı
- 1
- Insulation Materials
- Thermoplastic, Glass Filled
- Maks. Çalışma Sıcaklığı
- 125°C
- Contact Plating
- Gold
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 20mOhm
- Orientation
- Straight
- Radyasyon Dayanımı
- No
- Applications
- Automotive, General Purpose, Industrial, Telecommunications
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Max Voltage Rating Ac
- 1kV
- Insulation Height
- 0.335 8.51mm
- Yayın Yılı
- 2007
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Color
- Blue
- Number Of Contacts
- 6
- Reach Svhc
- No SVHC
- Stack Height
- 8.5mm
