Volume pricing
- 1+ pcs$3.33
- 10+ pcs$3.14
- 100+ pcs$2.97
- 500+ pcs$2.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pozisyon Sayısı
- 34
- Genişlik
- 8.4mm
- Style
- Board to Board
- Montaj Tipi
- Surface Mount, Right Angle
- Filter Feature
- NO
- Seri
- Dubox™
- Total Number Of Contacts
- 34
- Pitch Mating
- 0.100 2.54mm
- Mil Conformance
- NO
- Connector Type
- Receptacle
- Parça Durumu
- Active
- Terminal
- Solder
- Ambalaj
- Tube
- Row Spacing Mating
- 0.100 (2.54mm)
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 2
- Contact Resistance
- 20mOhm
- Housing Material
- Thermoplastic
- Contact Finish Post
- Tin
- Renk
- Grey
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 3A
- Min. Çalışma Sıcaklığı
- -65°C
- Applications
- Automotive, General Purpose, Industrial, Telecommunications
- Nominal Gerilim
- 1kV
- Fabrika Tedarik Süresi
- 8 Weeks
- Depth
- 8.4mm
- Insulation Materials
- Thermoplastic, Glass Filled
- Din Conformance
- NO
- HTS Kodu
- 8536.69.40.40
- Insulation Color
- Gray
- Fastening Type
- Push-Pull
- Material Flammability Rating
- UL94 V-0
- Gender
- Female
- Iec Conformance
- NO
- Contact Materials
- Phosphor Bronze
- Maks. Çalışma Sıcaklığı
- 125°C
- ECCN Kodu
- EAR99
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
