Specifications
- Renk
- Blue
- Min. Çalışma Sıcaklığı
- -55°C
- Nominal Gerilim
- 800V
- Contact Finish Thickness
- Flash
- Sıra Sayısı
- 1
- Depth
- 2.54mm
- Housing Material
- Polyester
- Number Of Conductors
- ONE
- Contact Style
- SQ PIN-SKT
- Polarization Key
- POLARIZED HOUSING
- Parça Durumu
- Obsolete
- Genişlik
- 2.54mm
- Contact Resistance
- 20mOhm
- Terminal
- Crimp
- Yükseklik
- 0.385 9.78mm
- Reference Standard
- UL, CSA
- Maks. Çalışma Sıcaklığı
- 120°C
- Seri
- Mini-Jump™
- Pitch
- 0.100 2.54mm
- RoHS Durumu
- RoHS Compliant
- Mounting Option1
- LOCKING
- Reliability
- COMMERCIAL
- Insulation Resistance
- 50GOhm
- Durability
- 50 Cycles
- Uzunluk
- 5.21mm
- Gender
- Female Sockets
- Max Voltage Rating Ac
- 800V
- Material Flammability Rating
- UL94 V-0
- Contact Finish
- Gold
- Tip
- Closed Top
- Current Rating Amps
- 3A
- Max Current Rating
- 2.5A
- Orientation
- Straight
- Number Of Contacts
- 2
- Contact Pattern
- RECTANGULAR
- Kurşunsuz
- Lead Free
- Number Of Positions Or Pins Grid
- 2 (1 x 2)
- Insertion Forcemax
- 4.448 N
- Ambalaj
- Bulk
- Contact Gender
- Female
