Volume pricing
- 1+ pcs$0.20
- 10+ pcs$0.19
- 100+ pcs$0.18
- 500+ pcs$0.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Polyester, Glass Filled
- Max Voltage Rating Ac
- 800V
- Akım Değeri
- 2.5A
- Depth
- 2.49mm
- Fabrika Tedarik Süresi
- 8 Weeks
- Pozisyon Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Resistance
- 50GOhm
- RoHS Durumu
- RoHS Compliant
- Current Rating Amps
- 3A
- Parça Durumu
- Active
- Genişlik
- 2.49mm
- Contact Finish Thickness
- 30.0μin 0.76μm
- Uzunluk
- 5.05mm
- Radyasyon Dayanımı
- No
- Number Of Contacts
- 2
- Contact Plating
- Gold
- Pitch
- 0.100 2.54mm
- Number Of Positions Or Pins Grid
- 2 (1 x 2)
- Yayın Yılı
- 2011
- Gender
- Female Sockets
- Sıra Sayısı
- 1
- Material Flammability Rating
- UL94 V-0
- Pin Sayısı
- 2
- Housing Color
- White
- Seri
- Mini-Jump™
- Tip
- Open Top
- Nominal Gerilim
- 800V
- Orientation
- Straight
- Contact Gender
- Female
- Renk
- White
- Maks. Çalışma Sıcaklığı
- 120°C
- Kurşunsuz
- Lead Free
- Min. Çalışma Sıcaklığı
- -55°C
- Yükseklik
- 0.236 6.00mm
- Reach Svhc
- No SVHC
- Contact Materials
- Bronze
- Contact Finish
- Gold
- Ambalaj
- Bulk
- Max Current Rating
- 2.5A
