Specifications
- Dielectric Withstanding Voltage
- 600VAC V
- Contact Finish Thickness Mating
- 100.0μin 2.54μm
- Number Of Contacts
- 84
- Additional Feature
- STANDARD: UL 94V-0
- Yayın Yılı
- 2014
- Pitch Post
- 0.100 2.54mm
- Contact Style
- BELLOWED TYPE
- Tip
- PLCC
- Body Length Or Diameter
- 1.417 inch
- ECCN Kodu
- EAR99
- Current Rating Amps
- 1A
- Ambalaj
- Tube
- Termination Post Length
- 0.126 3.20mm
- Number Of Positions Or Pins Grid
- 84 (4 x 21)
- REACH Uyumluluk Kodu
- compliant
- Çalışma Sıcaklığı
- -40°C~105°C
- Insulation Resistance
- 1000000000Ohm
- Contact Resistance
- 20mOhm
- Contact Configuration
- 21X21
- Contact Material Post
- Copper Alloy
- Body Breadth
- 1.417 inch
- Housing Material
- Polyphenylene Sulfide (PPS)
- JESD-609 Kodu
- e3
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 84
- Kurşunsuz Kodu
- yes
- Lead Pitch
- 2.54mm
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Contact Finish Mating
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Obsolete
- HTS Kodu
- 8536.69.40.40
- Contact Material Mating
- Copper Alloy
- Montaj Tipi
- Through Hole
- Özellikler
- Closed Frame
- Terminal
- Solder
- Material Flammability Rating
- UL94 V-0
- Body Depth
- 0.321 inch
- Pitch Mating
- 0.050 1.27mm
