Specifications
- Pozisyon Sayısı
- 15
- Shell Size Connector Layout
- 1 DE E High Density
- Uzunluk
- 30.81mm
- RoHS Durumu
- RoHS Compliant
- Contact Type
- Signal
- Sıra Sayısı
- 3
- Montaj
- Through Hole
- Çalışma Sıcaklığı
- -55°C~105°C
- Pitch
- 2.29mm
- Max Supply Voltage
- 250V
- Akım Değeri
- 2.5A
- Flange Feature
- Board Side (4-40); Mating Side, Female Screwlock (4-40)
- Ambalaj
- Tray
- Housing Material
- Thermoplastic
- Contact Materials
- Copper Alloy
- Contact Plating
- Gold, Tin
- Shell Material Finish
- Steel, Nickel Plated
- Renk
- Black
- Gender
- Female
- Parça Durumu
- Active
- Connector Type
- Receptacle, Female Sockets
- Fabrika Tedarik Süresi
- 13 Weeks
- Contact Finish
- Gold
- Current Rating Amps
- 2.5A
- Number Of Ports
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Style
- D-Sub, High Density
- Material Flammability Rating
- UL94 V-0
- Radyasyon Dayanımı
- No
- Orientation
- Straight
- Contact Finish Thickness
- Flash
- Montaj Tipi
- Through Hole
- Number Of Contacts
- 15
- Genişlik
- 6.1mm
- Min. Çalışma Sıcaklığı
- -55°C
- Dielectric Material
- Thermoplastic, Glass Filled
- Terminal
- Solder
- Nominal Gerilim
- 250V
- Seri
- 10090929
- Özellikler
- Board Lock
