Volume pricing
- 1+ pcs$3.78
- 10+ pcs$3.57
- 100+ pcs$3.36
- 500+ pcs$3.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fastening Type
- Push-Pull
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Polarization Key
- POLARIZED HOUSING
- Reference Standard
- UL, CSA
- Parça Durumu
- Active
- Pcb Contact Pattern
- RECTANGULAR
- Ambalaj
- Tube
- Contact Length Post
- 0.079 2.00mm
- Filter Feature
- NO
- Nominal Gerilim
- 200V AC/DC
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Body Breadth
- 0.157 inch
- RoHS Durumu
- RoHS Compliant
- Shrouding
- Unshrouded
- Plating Thickness
- 30μin
- Terminal
- Solder
- Contact Shape
- Square
- Number Of Positions Loaded
- All
- Ul Flammability Code
- 94V-0
- Min. Çalışma Sıcaklığı
- -55°C
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 2
- Style
- Board to Board or Cable
- Contact Plating
- GXT, Gold
- Mating Post Length
- 4mm
- Durability
- 100 Cycles
- Mixed Contacts
- NO
- Contact Type
- Male Pin
- Connector Type
- Header
- Uzunluk
- 48mm
- Current Rating Amps
- 2A AC/DC
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 2A
- Contact Finish Mating
- Gold
- Number Of Pcb Rows
- 2
- Row Spacing Mating
- 0.079 (2.00mm)
- Mil Conformance
- NO
- Max Voltage Rating Ac
- 650V
- Number Of Conductors
- ONE
- Montaj Tipi
- Through Hole
