Volume pricing
- 1+ pcs$0.79
- 10+ pcs$0.74
- 100+ pcs$0.70
- 500+ pcs$0.66
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Tape & Reel (TR)
- Genişlik
- 3.4mm
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Actuatorcolor
- Black
- Height Above Board
- 0.051 1.30mm
- Depth
- 3.4mm
- Montaj Tipi
- Surface Mount, Right Angle
- Insulation Resistance
- 100MOhm
- Contact Materials
- Copper Alloy
- Nominal Gerilim
- 50V
- Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 28
- Contact Location
- Bottom
- Çalışma Sıcaklığı
- -55°C~85°C
- Maks. Çalışma Sıcaklığı
- 85°C
- Number Of Contacts
- 28
- Fabrika Tedarik Süresi
- 15 Weeks
- Min. Çalışma Sıcaklığı
- -55°C
- Kurşunsuz
- Lead Free
- Current Rating Amps
- 0.5A
- Flat Flex Type
- FPC
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Seri
- VLL
- Akım Değeri
- 500mA
- Housing Color
- Natural
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Actuator Material
- Polyamide (PA9T), Nylon 9T, Glass Filled
- Cable End Type
- Tapered
- Uzunluk
- 16.5mm
- Contact Resistance
- 30mOhm
- Montaj
- Surface Mount
- Terminal
- Solder
- Orientation
- Right Angle
- Parça Durumu
- Active
- Locking Feature
- Flip Lock, Backlock
- Sıra Sayısı
- 1
- Contact Plating
- Gold
- Ffc Fcb Thickness
- 0.30mm
- Radyasyon Dayanımı
- No
