Specifications
- Actuator Material
- Polyamide (PA9T), Nylon 9T, Glass Filled
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2010
- Contact Resistance
- 30mOhm
- Montaj
- Surface Mount
- Cable End Type
- Tapered
- Uzunluk
- 8mm
- Ffc Fcb Thickness
- 0.30mm
- Contact Plating
- Gold
- Sıra Sayısı
- 1
- Locking Feature
- Flip Lock, Backlock
- Parça Durumu
- Active
- Terminal
- Solder
- Orientation
- Right Angle
- Max Voltage Rating Dc
- 50V
- Contact Finish Thickness
- 2.00μin 0.051μm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Finish
- Gold
- Radyasyon Dayanımı
- No
- Pitch
- 0.020 0.50mm
- Max Voltage Rating Ac
- 50V
- Actuatorcolor
- Black
- Height Above Board
- 0.051 1.30mm
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Genişlik
- 3.4mm
- Ambalaj
- Tape & Reel (TR)
- Pozisyon Sayısı
- 11
- Nominal Gerilim
- 50V
- Flammability Rating
- UL94 V-0
- Contact Materials
- Copper Alloy
- Insulation Resistance
- 100MOhm
- Montaj Tipi
- Surface Mount, Right Angle
- Depth
- 3.4mm
- Current Rating Amps
- 0.5A
- Kurşunsuz
- Lead Free
- Number Of Contacts
- 11
- Fabrika Tedarik Süresi
- 15 Weeks
- Min. Çalışma Sıcaklığı
- -55°C
- Maks. Çalışma Sıcaklığı
- 85°C
