Specifications
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Kurşunsuz Kodu
- yes
- Housing Material
- Thermoplastic
- Uzunluk
- 48.01mm
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tab Direction
- Up
- Fabrika Tedarik Süresi
- 7 Weeks
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e3
- Iec Conformance
- NO
- Contact Finish
- Gold
- Montaj
- Through Hole
- Voltage Rated Dc
- 125V
- Shell Material
- COPPER ALLOY
- Number Of Ports
- 3
- Renk
- Black
- Terminal
- Solder
- Özellikler
- Board Lock
- Filter Feature
- NO
- Din Conformance
- NO
- Pitch
- 2.03mm
- Max Voltage Rating Ac
- 125V
- Depth
- 15.75mm
- Empty Shell
- NO
- Montaj Tipi
- Through Hole
- Contact Resistance
- 20mOhm
- Contact Plating
- Gold, Nickel
- Sıra Sayısı
- 1
- Contact Materials
- Phosphor Bronze
- Number Of Positionscontacts
- 8p8c (RJ45, Ethernet)
- Seri
- RJHSE
- Çalışma Sıcaklığı
- -55°C~85°C
- Connector Type
- Jack
- Contact Finish Thickness
- 50.0μin 1.27μm
