Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 13.59mm
- Contact Resistance
- 20mOhm
- Montaj Tipi
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 15.75mm
- Reach Svhc
- Unknown
- Direction
- User Selectable
- Housing Material
- Thermoplastic
- Max Voltage Rating Ac
- 125V
- Pitch
- 2.03mm
- Çalışma Sıcaklığı
- -55°C~85°C
- Seri
- RJHSE
- Tab Direction
- User Selectable
- Number Of Positionscontacts
- 8p8c (RJ45, Ethernet)
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Yayın Yılı
- 2005
- Akım Değeri
- 1.5A
- ECCN Kodu
- EAR99
- Contact Finish Thickness
- 30.0μin 0.76μm
- Connector Type
- Jack
- Fabrika Tedarik Süresi
- 7 Weeks
- Led Color
- Green - Green
- Radyasyon Dayanımı
- No
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Insulation Resistance
- 500MOhm
- Terminal
- Solder
- Renk
- Black, Green
- Max Current Rating
- 1.5A
- Number Of Positions Loaded
- 8
- Özellikler
- Board Lock, Panel Stops
- Montaj
- Through Hole
- Gender
- Receptacle
- Contact Finish
- Gold
- Orientation
- Vertical
- Nominal Gerilim
- 125V
- Flammability Rating
- UL94 V-0
- Number Of Ports
- 1
