Volume pricing
- 1+ pcs$1.00
- 10+ pcs$0.95
- 100+ pcs$0.89
- 500+ pcs$0.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Contact Finish
- Gold
- Number Of Contacts
- 15
- Housing Material
- Thermoplastic
- Gender
- Receptacle
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Body Material
- Steel
- Connector Type
- Receptacle, Female Sockets
- Terminal Sayısı
- 15
- Contact Finish Thickness
- Flash
- Contact Type
- Signal
- Pozisyon Sayısı
- 15
- Ambalaj
- Tray
- Reach Svhc
- Unknown
- Kontak Formu
- Stamped
- Seri
- HD
- Dielectric Material
- Thermoplastic, Glass Filled
- Contact Materials
- Phosphor Bronze
- Current Rating Amps
- 3A
- Shell Material Finish
- Steel, Tin Plated
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Min. Çalışma Sıcaklığı
- -55°C
- Fabrika Tedarik Süresi
- 5 Weeks
- Parça Durumu
- Active
- Maks. Çalışma Sıcaklığı
- 105°C
- Orientation
- Right Angle
- Nominal Gerilim
- 250V
- Material Flammability Rating
- UL94 V-0
- Uzunluk
- 30.89mm
- Backset Spacing
- 0.350 (8.89mm)
- Çalışma Sıcaklığı
- -55°C~125°C
- Shell Size Connector Layout
- 1 DE E High Density
- Terminal
- Solder
- Genişlik
- 12.55mm
- Contact Plating
- Gold
- Özellikler
- Board Lock
- Connector Style
- D-Sub, High Density
- Sıra Sayısı
- 3
