Specifications
- Body Breadth
- 0.616 inch
- Parça Durumu
- Obsolete
- Reliability
- COMMERCIAL
- Contact Pattern
- RECTANGULAR
- RoHS Durumu
- RoHS Compliant
- Mating Contact Pitch
- 0.085 inch
- Connector Style
- Center Strip Contacts
- Empty Shell
- NO
- Total Number Of Contacts
- 50
- Shell Finish
- ZINC
- Pozisyon Sayısı
- 50
- Wire Size Min
- 30 AWG
- Flange Feature
- Housing/Shell (M2.6)
- Contact Finish
- Gold
- Shell Material
- STEEL
- Rated Current Signal
- 5A
- Mounting Option2
- SCREWLOCKS
- Reference Standard
- UL, CSA
- REACH Uyumluluk Kodu
- unknown
- Body Depth
- 0.91 inch
- Mixed Contacts
- NO
- Montaj Tipi
- Free Hanging (In-Line)
- Contact Design
- PREASSEM CONN
- Filter Feature
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Temperature Max
- 105°C
- Terminal
- Solder Cup
- Ul Flammability Code
- 94V-0
- Mounting Option1
- M3.5
- Mil Conformance
- NO
- Iec Conformance
- NO
- JESD-609 Kodu
- e4
- Contact Materials
- COPPER ALLOY
- Fabrika Tedarik Süresi
- 12 Weeks
- Yayın Yılı
- 2006
- Connector Type
- Plug
- Sıra Sayısı
- 2
- Din Conformance
- NO
- Insulation Materials
- DIALLYL PHTHALATE
- Özellikler
- Backshell, Cable Clamp
