Specifications
- Insulation Materials
- GLASS FILLED POLYESTER
- Seri
- 57
- Özellikler
- Backshell, Bail Lock, Cable Clamp
- Contact Finish Thickness
- 20.0μin 0.51μm
- Contact Gender
- MALE
- Additional Feature
- TOP CABLE ENTRY
- Operating Temperature Min
- -55°C
- Contact Materials
- NOT SPECIFIED
- Dielectric Withstanding Voltage
- 700VDC V
- Yayın Yılı
- 2005
- Fabrika Tedarik Süresi
- 12 Weeks
- Din Conformance
- NO
- Sıra Sayısı
- 2
- Connector Type
- Plug
- HTS Kodu
- 8536.69.40.30
- Terminal
- Solder Cup
- Mounting Option1
- M3.5
- Mil Conformance
- NO
- Iec Conformance
- NO
- REACH Uyumluluk Kodu
- unknown
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Filter Feature
- NO
- Montaj Tipi
- Free Hanging (In-Line)
- Operating Temperature Max
- 105°C
- Reference Standard
- UL, CSA
- Total Number Of Contacts
- 14
- Shell Finish
- ZINC
- Pozisyon Sayısı
- 14
- Rated Current Signal
- 5A
- Shell Material
- STEEL
- Contact Finish
- Gold
- Mating Contact Pitch
- 0.085 inch
- ECCN Kodu
- EAR99
- Connector Style
- Center Strip Contacts
- Empty Shell
- NO
- Body Breadth
- 0.645 inch
- Body Length Or Diameter
- 1.417 inch
- Option
- GENERAL PURPOSE
- Reliability
- COMMERCIAL
