4340

Specifications

Çalışma Sıcaklığı

-40°C ~ 85°C

Ürün Tipi

Cable Mounts

Pozisyon Sayısı

10

Alternate Pn

CH R-35-P

RoHS

Details

Contact Shape

Square

Connector Type

Header

Fabrika Tedarik Süresi

12 Weeks

Birim Ağırlık

0.211644 oz

Shrouding

Shrouded - 1 Wall

Akım Değeri

3A per Contact

Fastening Type

Friction Lock

Ambalaj

Bulk

Contact Finish Thickness Mating

3.90µin (0.099µm)

Overall Contact Length

0.378 (9.60mm)

Montaj Tipi

Through Hole

Number Of Positions Loaded

All

Container Type

Case

Boyut / Ölçü

3.346Lx2.165W 85.00mmx55.00mm

Özellikler

Heat Sink

Seri

IL-G

Style

Board to Cable/Wire

Contact Finish Mating

Gold

Sıra Sayısı

1

Contact Type

Male Pin

Material

Metal, Aluminum

Pitch Mating

0.098 (2.50mm)

Contact Materials

Brass

Renk

Black

Parça Durumu

Active

Tip

Cable Holder

Nem Hassasiyeti (MSL)

1 (Unlimited)

Fabrika Paket Adedi

5000

Insulation Height

0.280 (7.10mm)

Mated Stacking Heights

10mm

Insulation Materials

Polyamide (PA66), Nylon 6/6

Contact Lengthmating

0.157 (4.00mm)

Design

Hand Held

Material Flammability Rating

UL94 V-0

Insulation Color

Brown
