2365

Specifications

Total Number Of Contacts

72

Plating Thickness

FLASH inch

Body Depth

0.512 inch

Bodyshell Style

RECEPTACLE

Body Breadth

0.197 inch

Seri

PI

Rated Current Signal

3A

Mating Contact Pitch

0.1 inch

Terminal Adımı

2.54mm

Number Of Pcb Rows

2

Tip

Base

JESD-609 Kodu

e4

Body Length Or Diameter

3.6 inch

Material

Polycarbonate (PC)

Reliability

COMMERCIAL

Insulation Resistance

5000000000Ohm

Contact Finish Termination

Gold (Au) - with Nickel (Ni) barrier

Montaj Stili

STRAIGHT

Renk

Purple

Sıra Sayısı

2

RoHS Durumu

ROHS3 Compliant

Contact Finish Mating

AU ON NI

Parça Durumu

Active

Contact Resistance

20mOhm

Boyut / Ölçü

2.900Lx2.500W x 1.000 H 73.66mmx63.50mmx25.40mm

Özellikler

Raspberry Pi A+

Number Of Conductors

ONE

Contact Pattern

RECTANGULAR

Additional Feature

ROHS COMPLIANT

Mating Contact Row Spacing

0.1 inch

Operating Temperature Min

-55°C

Length Termination

0.236 inch

Reference Standard

UL, CSA

Pcb Contact Pattern

RECTANGULAR

Contact Gender

MALE

Operating Temperature Max

105°C

Nem Hassasiyeti (MSL)

Not Applicable

Pcb Contact Row Spacing

2.54 mm

Dielectric Withstanding Voltage

1000VAC V
