2167

Specifications

Insulation Materials

POLYBUTYLENE TEREPHTHALATE

Contact Resistance

20mOhm

Fabrika Tedarik Süresi

2 Weeks

JESD-609 Kodu

e3

Number Of Pcb Rows

2

Operating Temperature Max

105°C

Body Depth

0.28 inch

Insulator Color

BLACK

Connector Type

BOARD CONNECTOR

Montaj Stili

RIGHT ANGLE

HTS Kodu

8536.69.40.40

Body Length Or Diameter

1.6 inch

Output Configuration

Open Collector

Dielectric Withstanding Voltage

1000VAC V

Kablo Uzunluğu

9.20 234.00mm

Main Purpose

Lighting Kit

Operating Temperature Min

-55°C

Total Number Of Contacts

32

Mating Contact Pitch

0.1 inch

Besleme Gerilimi

3.3V~5.5V

Reliability

COMMERCIAL

Nem Hassasiyeti (MSL)

1 (Unlimited)

Durability

1000 Cycles

Parça Durumu

Active

REACH Uyumluluk Kodu

compliant

Contact Materials

BRASS

Sensing Method

Cross-beam

ECCN Kodu

EAR99

Light Source

Infrared

Pcb Contact Pattern

RECTANGULAR

Body Breadth

0.197 inch

Montaj Tipi

BOARD

Terminal Adımı

2.54mm

Connection Method

Wire Leads

Response Time

2ms

Number Of Conductors

ONE

Rated Current Signal

3A

Contact Finish Mating

SN ON NI

Pcb Contact Row Spacing

2.54 mm

Contact Gender

MALE
