Volume pricing
- 1+ pcs$4.55
- 10+ pcs$4.29
- 100+ pcs$4.05
- 500+ pcs$3.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Çalışma Sıcaklığı
- -55°C~105°C
- Housing Material
- Polyester
- Insulation Height
- 0.425 10.80mm
- Working Voltage
- 350V
- Akım Değeri
- 1A
- Renk
- Grey
- Contact Finish Post
- Gold
- Pitch Mating
- 0.100 2.54mm
- Hole Diameter
- 890 μm
- Nominal Gerilim
- 1000V
- Fastening Type
- Push-Pull
- Min. Çalışma Sıcaklığı
- -55°C
- Contact Finish Thickness Post
- Flash
- Contact Materials
- Copper Alloy
- Kurşunsuz
- Lead Free
- Depth
- 7.1mm
- Material
- Glass, Polyester
- Number Of Poles
- 26
- Max Current Rating
- 1A
- Terminal
- Kinked Pin, Solder
- Özellikler
- Polarizing Key
- Contact Length Post
- 0.110 2.79mm
- Style
- Board to Board or Cable
- Number Of Contacts
- 26
- Ambalaj
- Bulk
- Sıra Sayısı
- 2
- Number Of Positions Loaded
- All
- Pozisyon Sayısı
- 26
- Uzunluk
- 37.5mm
- Contact Type
- Female Socket
- Pin Sayısı
- 26
- Orientation
- Straight
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 8 Weeks
- Insulation Resistance
- 1GOhm
- Housing Color
- Grey
- Current Rating Amps
- 1A
- Yayın Yılı
- 2003
- Lead Length
- 2.8mm
- Material Flammability Rating
- UL94 V-0
