Specifications
- Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Tip
- PLCC
- Gender
- Female
- Contact Finish Thickness Post
- 160.0μin 4.06μm
- Seri
- 8400
- Number Of Contacts
- 52
- Kurşunsuz
- Lead Free
- Contact Resistance
- 15mOhm
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Termination Post Length
- 0.132 3.35mm
- Ambalaj
- Tube
- Contact Finish Post
- Tin
- Contact Finish Thickness Mating
- 160.0μin 4.06μm
- Pitch
- 2.54mm
- Min. Çalışma Sıcaklığı
- -40°C
- Lead Pitch
- 1.27mm
- Pin Sayısı
- 52
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- Socket
- Row Spacing
- 15.24 mm
- Housing Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Parça Durumu
- Active
- Number Of Positions Or Pins Grid
- 52 (4 x 13)
- Özellikler
- Closed Frame
- Yayın Yılı
- 2006
- Fabrika Tedarik Süresi
- 8 Weeks
- Contact Material Post
- Copper Alloy
- Genişlik
- 25.88mm
- Terminal
- Solder
- Çalışma Sıcaklığı
- -40°C~105°C
- RoHS Durumu
- RoHS Compliant
- Yükseklik
- 8mm
- Pozisyon Sayısı
- 52
- Insulation Resistance
- 1kOhm
- Maks. Çalışma Sıcaklığı
- 105°C
- Material Flammability Rating
- UL94 V-0
- Contact Plating
- Tin
- Uzunluk
- 25.88mm
