Volume pricing
- 1+ pcs$31.21
- 10+ pcs$29.44
- 100+ pcs$27.78
- 500+ pcs$26.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gender
- Receptacle
- Sıra Sayısı
- 3
- Number Of Contacts
- 50
- Kılıf / Paket
- Metal
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- IDC, Ribbon Cable
- Akım Değeri
- 1A
- Pitch
- 2.74mm
- Current Rating Amps
- 1A
- Connector Type
- Receptacle, Female Sockets
- Renk
- Gray
- Flange Feature
- Housing/Shell (4-40)
- Connector Style
- D-Sub
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Uzunluk
- 70.9mm
- Wire Gauge
- 26-28 AWG
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 22.05mm
- Shell Size Connector Layout
- 5 DD D
- Ambalaj
- Tray
- Max Current Rating
- 1A
- Min. Çalışma Sıcaklığı
- -55°C
- Contact Type
- Signal
- Lead Pitch
- 2.74mm
- Pozisyon Sayısı
- 50
- Insulation Materials
- Polyester
- Contact Finish Thickness
- 30.0μin 0.76μm
- Contact Plating
- Gold
- Housing Color
- Grey
- Contact Materials
- Copper Alloy
- Voltage Rated Ac
- 350V
- Depth
- 15.2mm
- Terminal Sayısı
- 50
- Voltage Rated Dc
- 350V
- Maks. Çalışma Sıcaklığı
- 105°C
- Orientation
- Right Angle
- Number Of Ports
- 1
- RoHS Durumu
- RoHS Compliant
- Plating
- Steel
- Yayın Yılı
- 2002
