81060-500203-RB

Specifications

Fabrika Tedarik Süresi

9 Weeks

Çalışma Sıcaklığı

-55°C~105°C

Parça Durumu

Active

Pozisyon Sayısı

60

Insulation Color

Black

Contact Length Post

0.090 2.29mm

Row Spacing Mating

0.100 (2.54mm)

Insulation Height

0.310 7.87mm

Yükseklik

7.87mm

Housing Material

Plastic

Style

Board to Cable/Wire

Contact Finish Post

Tin

Montaj

Through Hole

Connector Type

Header

Seri

810

Renk

Black

Current Rating Amps

0.75A

Genişlik

10.3mm

Contact Finish Mating

Gold

Pitch Mating

0.050 1.27mm

Contact Finish Thickness Post

250.0μin 6.35μm

Sıra Sayısı

2

Housing Color

Black

Number Of Positions Loaded

All

Fastening Type

Push-Pull

Pitch

1.27mm

Yayın Yılı

2013

Akım Değeri

500mA

Kurşunsuz

Lead Free

RoHS Durumu

RoHS Compliant

Terminal

Solder

Contact Lengthmating

0.140 3.56mm

Ambalaj

Bulk

Contact Type

Male Pin

Montaj Tipi

Through Hole, Right Angle

Material Flammability Rating

UL94 V-0

Insulation Materials

Liquid Crystal Polymer (LCP)

Shrouding

Shrouded - 4 Wall

Contact Shape

Square

Nem Hassasiyeti (MSL)

1 (Unlimited)
