Specifications
- Flammability Rating
- UL94 V-0
- RoHS Durumu
- ROHS3 Compliant
- Shrouding
- Shrouded - 4 Wall
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Parça Durumu
- Active
- Contact Plating
- Gold
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -65°C~125°C
- Min. Çalışma Sıcaklığı
- -55°C
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Current Rating Amps
- 1A
- Yayın Yılı
- 2013
- Pitch Mating
- 0.050 1.27mm
- Özellikler
- Keying Slot
- Contact Finish Thickness Post
- 200.0μin 5.08μm
- Pozisyon Sayısı
- 30
- Housing Material
- Liquid Crystal Polymer
- Contact Shape
- Square
- Contact Gender
- Male
- Pitch
- 1.27mm
- Maks. Çalışma Sıcaklığı
- 105°C
- Contact Finish Mating
- Gold
- Contact Length Post
- 0.094 2.40mm
- Contact Type
- Male Pin
- Style
- Board to Cable/Wire
- Seri
- 452
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Finish Post
- Tin
- Number Of Positions Loaded
- All
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Akım Değeri
- 1A
- Ambalaj
- Tray
- Connector Type
- Header
- Contact Materials
- Copper Alloy
- Nominal Gerilim
- 125V
- Insulation Height
- 0.210 5.33mm
- Montaj
- Through Hole
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 10 Weeks
- Sıra Sayısı
- 2
