Volume pricing
- 1+ pcs$6.59
- 10+ pcs$6.22
- 100+ pcs$5.87
- 500+ pcs$5.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nominal Gerilim
- 125V
- Contact Materials
- Copper Alloy
- Sıra Sayısı
- 2
- Fabrika Tedarik Süresi
- 10 Weeks
- Terminal
- Solder
- Insulation Height
- 0.222 5.65mm
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole
- Number Of Contacts
- 16
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Type
- Male Pin
- Contact Length Post
- 0.094 2.40mm
- Style
- Board to Cable/Wire
- Seri
- 452
- Akım Değeri
- 1A
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Number Of Positions Loaded
- All
- Contact Finish Post
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gender
- Male
- Ambalaj
- Tray
- Connector Type
- Header
- Yayın Yılı
- 2013
- Current Rating Amps
- 1A
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Stack Height Mating
- 5.84mm 6.60mm 7.21mm 8.13mm
- Min. Çalışma Sıcaklığı
- -55°C
- Özellikler
- Keying Slot
- Pitch Mating
- 0.050 1.27mm
- Contact Finish Thickness Post
- 200.0μin 5.08μm
- Pozisyon Sayısı
- 16
- Housing Material
- Liquid Crystal Polymer
- Pitch
- 1.27mm
- Contact Gender
- Male
- Contact Shape
- Square
- Maks. Çalışma Sıcaklığı
- 105°C
- Contact Finish Mating
- Gold
- Flammability Rating
- UL94 V-0
- Shrouding
- Shrouded - 4 Wall
- Orientation
- Straight
