Specifications
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Type
- Header
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pozisyon Sayısı
- 4
- Housing Material
- Liquid Crystal Polymer
- Montaj
- Through Hole
- Contact Finish Mating
- Gold
- Akım Değeri
- 1A
- Insulation Height
- 0.222 5.65mm
- Contact Plating
- Gold
- Number Of Contacts
- 4
- Pitch
- 1.27mm
- Özellikler
- Keying Slot
- Parça Durumu
- Active
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Current Rating Amps
- 1A
- RoHS Durumu
- ROHS3 Compliant
- Style
- Board to Cable/Wire
- Contact Finish Post
- Tin
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Seri
- 452
- Stack Height Mating
- 5.84mm 6.60mm 7.21mm 8.13mm
- Montaj Tipi
- Through Hole
- Shrouding
- Shrouded - 4 Wall
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 125V
- Sıra Sayısı
- 2
- Çalışma Sıcaklığı
- -65°C~125°C
- Number Of Positions Loaded
- All
- Contact Shape
- Square
- Gender
- Male
- Yayın Yılı
- 2013
- Contact Length Post
- 0.094 2.40mm
- Row Spacing Mating
- 0.050 (1.27mm)
- Material Flammability Rating
- UL94 V-0
- Contact Type
- Male Pin
- Contact Materials
- Copper Alloy
- Pitch Mating
- 0.050 1.27mm
- Terminal
- Solder
- Ambalaj
- Tray
