Volume pricing
- 1+ pcs$2.81
- 10+ pcs$2.65
- 100+ pcs$2.50
- 500+ pcs$2.36
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 6 Weeks
- Insulation Resistance
- 1GOhm
- Özellikler
- Feed Through, Polarizing Key
- Max Current Rating
- 1A
- Contact Resistance
- 20mOhm
- Wire Type
- Ribbon Cable
- Wire Gauge
- 26-28 AWG, Stranded or Solid
- Gender
- Receptacle
- Contact Gender
- Female
- Wirecable Type
- Ribbon
- Flammability Rating
- UL94 V-0
- Montaj
- Cable, Free Hanging
- Maks. Çalışma Sıcaklığı
- 105°C
- Contact Materials
- Copper
- Pozisyon Sayısı
- 40
- Depth
- 7.6mm
- Orientation
- Right Angle
- Kurşunsuz
- Lead Free
- Cable Termination
- IDC
- Seri
- 3000
- Number Of Poles
- 40
- Montaj Tipi
- Free Hanging (In-Line)
- Material
- Glass, PBT, Polyester
- Wire Gauge Min
- 26 AWG
- Lead Pitch
- 2.54mm
- Akım Değeri
- 1A
- Housing Color
- Grey
- Uzunluk
- 55.4mm
- Hole Diameter
- 890 μm
- Number Of Contacts
- 40
- Reach Svhc
- No SVHC
- Connector Type
- Receptacle
- Contact Type
- Female Socket
- Pitch
- 0.100 2.54mm
- Yayın Yılı
- 2001
- Wire Gauge Max
- 28 AWG
- Contact Plating
- Gold, Nickel
- Voltage Rated Dc
- 350V
- Row Spacing
- 0.100 (2.54mm)
- Contact Current Rating
- 1A
