3408-5303

Specifications

Weight

680.388555g

Fastening Type

Latch Lock/Eject Hooks, Long

Montaj Tipi

Through Hole, Right Angle

Renk

Grey

Pitch

2.54mm

Genişlik

17.3mm

Contact Finish Thickness Mating

30.0μin 0.76μm

Pitch Mating

0.100 2.54mm

Number Of Contacts

16

Ambalaj

Bulk

Insulation Resistance

1GOhm

Çalışma Sıcaklığı

-55°C~105°C

Fabrika Tedarik Süresi

6 Weeks

Contact Finish Post

Tin-Lead

Contact Plating

Gold

Contact Length Post

0.155 3.94mm

Seri

3000

Sıra Sayısı

2

Row Spacing Mating

0.100 (2.54mm)

Contact Shape

Square

Pozisyon Sayısı

16

Contact Type

Male Pin

Min. Çalışma Sıcaklığı

-55°C

Contact Materials

Copper Alloy

Lead Pitch

2.54mm

Current Rating Amps

1.75A

Contact Lengthmating

0.240 6.10mm

Uzunluk

39.7mm

Shrouding

Shrouded - 4 Wall

Housing Color

Grey

Akım Değeri

1A

Özellikler

Keying Slot, Mounting Flange

Contact Finish Thickness Post

200.0μin 5.08μm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Material Flammability Rating

UL94 V-0

Connector Type

Header

Contact Finish Mating

Gold

Montaj

Through Hole

Parça Durumu

Last Time Buy

Nominal Gerilim

125V
