Volume pricing
- 1+ pcs$11.04
- 10+ pcs$10.42
- 100+ pcs$9.83
- 500+ pcs$9.27
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pozisyon Sayısı
- 60
- Uzunluk
- 80.8mm
- Cable Termination
- IDC
- Seri
- 3000
- Nominal Gerilim
- 500V
- Max Current Rating
- 1A
- Number Of Contacts
- 60
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 20mOhm
- Min. Çalışma Sıcaklığı
- -55°C
- Pitch
- 0.100 2.54mm
- Contact Materials
- Copper
- Contact Plating
- Gold
- Depth
- 7.6mm
- Wirecable Type
- Ribbon
- Insulation Resistance
- 1GOhm
- Sıra Sayısı
- 2
- Number Of Poles
- 60
- Kurşunsuz
- Lead Free
- Wire Type
- Ribbon Cable
- Parça Durumu
- Active
- Özellikler
- Feed Through, Polarizing Key
- Onay Kuruluşu
- UL
- Hole Diameter
- 890 μm
- Material
- Glass, PBT, Polyester
- Wire Gauge
- 26-28 AWG, Stranded or Solid
- Housing Material
- Polyester
- Terminal
- IDT
- Working Voltage
- 350V
- Maks. Çalışma Sıcaklığı
- 105°C
- Weight
- 1.088622kg
- Reach Svhc
- No SVHC
- Gender
- Receptacle
- Wire Gauge Min
- 26 AWG
- Housing Color
- Grey
- Montaj
- Cable, Free Hanging
- Insulation Materials
- Polyester
- Wire Gauge Max
- 28 AWG
- Contact Type
- Female Socket
- Flammability Rating
- UL94 V-0
