Volume pricing
- 1+ pcs$0.57
- 10+ pcs$0.54
- 100+ pcs$0.51
- 500+ pcs$0.48
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Through Hole
- Housing Material
- Polyester
- Pitch
- 2.54mm
- Style
- Board to Board or Cable
- Housing Color
- Black
- Fabrika Tedarik Süresi
- 9 Weeks
- Gender
- Male
- Yayın Yılı
- 2008
- Orientation
- Straight
- Maks. Çalışma Sıcaklığı
- 105°C
- Parça Durumu
- Active
- Shrouding
- Shrouded - 4 Wall
- Pitch Mating
- 0.100 2.54mm
- Contact Materials
- Brass
- Contact Finish Thickness Mating
- Flash
- Contact Finish Mating
- Gold
- Min. Çalışma Sıcaklığı
- -55°C
- Number Of Positions Loaded
- All
- Seri
- 303
- Contact Type
- Male Pin
- Contact Length Post
- 0.110 2.79mm
- Insulation Color
- Black
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Thickness Post
- Flash
- Contact Lengthmating
- 0.236 6.00mm
- Max Current Rating
- 1A
- Insulation Materials
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Number Of Contacts
- 20
- Contact Shape
- Square
- Row Spacing Mating
- 0.100 (2.54mm)
- Montaj
- Through Hole
- Özellikler
- Keying Slot
- Fastening Type
- Push-Pull
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 8.78mm
- Current Rating Amps
- 1A
- Pozisyon Sayısı
- 20
- Contact Plating
- Gold
- Çalışma Sıcaklığı
- -55°C~105°C
- Ambalaj
- Bulk
