2560-5002UB

Specifications

Housing Color

Grey

Contact Length Post

0.112 2.84mm

Insulation Color

Black

Lead Pitch

2.54mm

Terminal

Solder

Insulation Materials

Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled

Contact Lengthmating

0.243 6.17mm

Row Spacing Mating

0.100 (2.54mm)

Material Flammability Rating

UL94 V-0

Nem Hassasiyeti (MSL)

1 (Unlimited)

Current Rating Amps

1.75A

Weight

1.088622kg

Renk

Grey

Parça Durumu

Active

Contact Plating

Gold

Pitch Mating

0.100 2.54mm

Reach Svhc

Unknown

Contact Materials

Copper Alloy

Insulation Height

0.338 8.59mm

Pitch

2.54mm

Montaj

Through Hole

Sıra Sayısı

2

Contact Type

Male Pin

RoHS Durumu

Non-RoHS Compliant

Kurşunsuz

Contains Lead

Contact Finish Thickness Post

200.0μin 5.08μm

Yayın Yılı

2009

Number Of Positions Loaded

All

Contact Finish Mating

Gold

Maks. Çalışma Sıcaklığı

105°C

Style

Board to Board or Cable

Seri

2500

Özellikler

Keying Slot

Min. Çalışma Sıcaklığı

-55°C

Number Of Contacts

60

Contact Finish Post

Tin-Lead

Montaj Tipi

Through Hole, Right Angle

Orientation

Right Angle

Connector Type

Header

Fabrika Tedarik Süresi

6 Weeks
